SECTION 8: Specifications and Safety
2025653-048 Revision B Responder
2000 Page 119
J214 – LCD Panel
Hirose FH12-40-S-0.5SH
Pin
Number
Name Description
1-4, 6,
31,36
NC No Connection
5, 10, 14,
18, 22, 26,
30, 32, 34
GND System Ground
7 LCD_R0 Output - Red Bit 0
8 LCD_R1 Output - Red Bit 1
9 LCD_R2 Output - Red Bit 2
11 LCD_R3 Output - Red Bit 3
12 LCD_R4 Output - Red Bit 4
13 LCD_R5 Output - Red Bit 5
15 LCD_G0 Output – Green Bit 0
16 LCD_G1 Output – Green Bit 1
17 LCD_G2 Output – Green Bit 2
19 LCD_G3 Output – Green Bit 3
20 LCD_G4 Output – Green Bit 4
21 LCD_G5 Output – Green Bit 5
23 LCD_B0 Output - Blue Bit 0
24 LCD_B1 Output - Blue Bit 1
25 LCD_B2 Output - Blue Bit 2
27 LCD_B3 Output - Blue Bit 3
28 LCD_B4 Output - Blue Bit 4
29 LCD_B5 Output - Blue Bit 5
33 LCD_FPSHFT Output - LCD Pixel Shift
