SECTION 4: Repair
2025653-048 Revision B Responder
™
2000 Page 44
SPO
2
Board Installation
Assembly Step Details
Perform the Following step
only if the SPO2 option is
installed.
Connect the ECG/SPO2
cable to X16 on the SPO2
Board.
Connect X14 on the SPO2
Board to J221 on the Main
Board and then secure with
four Phillips screws.
Figure 49: SPO
2
Cable
Installed
Figure 50: SPO
2
Board
Installation
Figure 51: SPO
2
Board
Installed
