Section 5: Performance Verification and Safety Testing
2025653-048 Revision B Responder
™
2000 Page 55
Printer Speed Test
Prints a test strip at a constant speed of 25 mm/s with a 25 mm period and 25 mm amplitude:
Battery Readings
Heading Description
Full Capacity
Capacity of a fully charged battery
Rem. Capacity
Current battery charge
Rel. Capacity
Current charge as a percentage of the full capacity
Normally this screen is used to verify the battery is charging (or fully charged) at the appropriate voltage. Service tests
must be performed with the battery at least 20% charged.
• New batteries have a full capacity of at least 6000 mAH and will charge when the Responder 2000 is plugged
into an AC outlet.
• If the battery is fully charged and has a capacity of less than 4500 mAH, calibrate the battery (see Battery
Calibration on page11).
• If the battery still has a capacity of less than 4500 mAH after calibration, then replace the battery.
