GE Responder 2000 Service Manual

SECTION 8: Specifications and Safety
2025653-048 Revision B Responder
™
2000 Page 116
8 LL Input – Left Leg
9 NC No Connection
10 NC No Connection
11 SHLD Shield
ECG Cable Identification Encoding
ECG Cables available for use with the Cardiac Science Responder 2000 have identification features to enable
identification of the cable type. Cable connections are shown here:
Cable Connections for 5 lead, 3 lead and sync cables.
ECG Connector Cable Connections
Pin
Number
Pin
Name
5 Lead Cable 3 Lead Cable Sync Cable
1 RA RA RA
- Attenuated
Sync Input
2 NC
3 NC
4 LA LA LA
Center-tap
Attenuated
Sync Input
5 RL RL
6 V V
130M
resistor
Pin 5 to Pin 6
33M
resistor
Pin 5 to Pin 6
7 NC
8 LL LL LL
+ Attenuated
Sync Input
9 NC
10 NC
11 SHLD Shield Shield
