SECTION 8: Specifications and Safety
2025653-048 Revision B Responder
2000 Page 128
J102 PDLHV_APEX Patient Connection – Apex
J104, J105, J106, J107 – Energy Storage Capacitor Connectors
Keystone 1287-ST
Pin
Number
Name Description
J104 HVCAP1_POS Energy Storage Capacitor 1 – Pos
J105 HVCAP1_NEG Energy Storage Capacitor 1 – Neg
J106 HVCAP2_POS Energy Storage Capacitor 2 – Pos
J107 HVCAP2_NEG Energy Storage Capacitor 2 – Neg
J126, J127 – Internal Test Load Resistor
Keystone 1287-ST
Pin
Number
Name Description
J126 TESTLOAD1 Connects to a paddle cradle
J127 TESTLOAD2 Connects to a paddle cradle
ECG PCBA
The ECG PCBA is a monitoring ECG subsystem. All operations are performed per serial communications with the main
CPU PCBA.
J412 – Interface to main CPU PCBA
Power and serial communications are carried through this connector.
SAMTEC BCS-104-L-D-PE-BE
Pin
Number
Name Description
1 GND System Ground
2 SER_CPU2ECG Logic Level Serial Data Input
3 GND System Ground
4 SER_ECG2CPU Logic Level Serial Data Input
5 GND System Ground
