GRAUPNER mz-24 PRO Programming Manual

With older transmitters of the D and FM type, check
the servo direction and control mode and change
them if necessary by switching the corresponding ca-
bles. If necessary, turn off all the mixers or set them
to zero.
Notices
• Failure to assign a control in the PUPIL trans-
mitter will result in the relevant servo(s) remain-
ing in middle position after transferring control
functions to the PUPIL transmitter.
• Regardless of the type of RF link between
the TEACH transmitter and model, the PUPIL
transmitter should always be operated in nor-
mal PPM mode.
Teacher/Pupil Function
Both transmittersare connected to each other using
an appropriatecable. Refer to the Trainer Cable sec-
tion (page 143).Insert the plug identified as M (mas-
ter) in the TEACH transmitter socket, and insert the
plugwithS (student) inthe PUPIL transmitter socket
(this many vary depending on the cable).
Attention
BEFORE starting trainer mode for the operational
model, always make sure all functions have been
correctly transferred.
Notice
Do not insert a 3-pin jack plug trainer cable into
the DSC system socket; it is not designed for this
purpose. The DSC socket can only be used for
cables with a 2-pin jack plug.
Trainer Cable
4179.1 Trainer cable to connect any two Graupner
transmitters with a DSC socket. This cable
has a 2-pin jack plug on both ends.
3290.7 Trainer cable to connect a TEACH transmit-
ter with a DSC socket to a Graupner PUPIL
transmitter with a PUPIL socket for the op-
toelectronic system. This cable has a 2-pin
jack plug on the M side and a 3-pin jack
plug on the S side. (Example: an mz-24 Pro
to an mc-16, or a transmitter retrofitted with
a DSC module - order No. 3290.24)
3290.8 Trainer cable to connect a TEACH trans-
mitter having a socket for the optoelectron-
ic system to a Graupner PUPIL transmitter
with a DSC socket. This cable has a 3-pin
jack plug on the M side and a 2-pin jack
plug on the S side. (Example: an mc-16 to
an mz-24 Pro, or a transmitter retrofitted
with a DSC module - order No. 3290.24)
Additional information on the cables and modules
mentioned in thissection for the TEACH and PUPIL
transmitters can be found in the relevanttransmitter
instructionsin the main Graupner FS catalogue, and
on the Internet at www.graupnerusa.com.
143
Function menu | general - Trainer
