Announce
User Voice Recordings
To change the voice recording settings, from the main
display press the BASE menu gear icon (green “B”) to
bring up the BASE submenu screen:
000
000
000
000
mz
000%
000%
000
000
BATT TIME 00: 01: 23
MODELLNAME 1
M - 1
PHASE 1
000:00.0
000:00.0
4.2V
0:01:23
Press
From the BASE submenu display, press the An-
nounce icon:
BACK
SYSTEM
BASE
FUNCTION
Model Sel
E.P.A
Model Type
REV/SUB
THR.CUT
Timer
TX ctl
Fail Safe
Trim Step
Servo
Out.Swap
CTL Set
Announce
Telemetry
Press
Saved in the mz-24 Pro HoTT transmitter memory,
near the datafiles for the other transmitter announce-
ments, are the User-Voice-Files, numbered from
285 to 294. These special announcements can be
replaced by user-created .wav files via the Firmware_
Upgrade_grStudio. All voice files can be assigned as
phase-specific or phase-crossing in the BASE sub-
menu Announces.
Phase Depending Settings
This submenu allows for different phase-specific val-
ues to be programmed. Phase names are displayed
in green in the upper left side of the screen next to
the BACK button. Standard default naming for the
phases are usually displayed as NORMAL/PHASE
1. (Additional phases will be named numerically, e.g.
Phase 2, Phase 3, etc.) To define multiple phases,
refer to the FUNCTION submenu Phase section (page
120). Each new phase will need to be assigned to a
different switch. To change the phases, activate the
corresponding switch(es).
CTL Column
Use this column to assign a switch to the announce-
ment:
BACK
PHASE 1
SERVO
INC
RES
DEC
1.
NULL
2.
NULL
3.
NULL
4.
CTL PHASE
CO
CO
CO
CO
ANNOUNCEMENT
Announce
5.
SW 3
NULL
CO
NEXT
Refer to the Control and Switch Assignment section
(page 26) for information on how to assign switches.
Notices
Free switch assignment is only possible when the
value field of the PHASE column is CO. When the
PHASE value is SE, only switches that are not
already assigned to a model memory phase will be avail-
able. This prevents error functions.
PHASE Column
In this column changes between CO (common), model
memory specific, and SE (single), phase specific an-
nounce. Press the value field of the value to change:
BACK
PHASE 1
SERVO
INC
RES
DEC
1.
NULL
2.
NULL
3.
NULL
4.
CTL PHASE
CO
CO
CO
CO
ANNOUNCEMENT
Announce
5.
SW 3
NULL
CO
NEXT
Press
BACK
PHASE 1
SERVO
INC
RES
DEC
1.
NULL
2.
NULL
3.
NULL
4.
CTL PHASE
SE
CO
CO
CO
Announcement
Announce
5.
SW 3
NULL
CO
NEXT
ANNOUNCEMENT Column
Use this column to activate, according to the switch
position and phase, a User_Voice announcement.
Press the value field in the ANNOUNCEMENT col-
umn:
BACK
PHASE 1
SERVO
INC
RES
DEC
1.
NULL
2.
NULL
3.
NULL
4.
CTL PHASE
SE
CO
CO
CO
Announcement
Announce
5.
SW 3
NULL
CO
NEXT
Press
The field highlights blue:
118 Base menu - Announces
