Before Use
Thank you very much for purchasing the Graupner
mz-24 HoTT Pro transmitter.
This transmitter comes with two manuals: Part 1 is a
quick-start guide included in the transmitter’s pack-
aging. Part 2 is a programming manual providing
in-depth details about the advanced functions of the
mz-24 PRO. Both manuals are available for down-
load at www.graupnerusa.com.
Carefully read both manuals for all safety precautions
and for information on optimal transmitter and model
use. If you experience any trouble during operation,
ask experienced modelers, your dealer or contact the
Graupner Service Center.
For ease-of-use in locating specific information, cer-
tain sections in this manual are marked with the same
model type symbols used in the transmitter display
menus. Icons will be highlighted blue when pertaining
to the model it represents; icons will be grayed out if
the information is irrelevant to that model. Refer to
the highlighted icons for information related to your
model type:
Warning ............................................................... 210
Etc. Set ................................................................ 212
Display ................................................................. 216
Stick Cali - Stick Calibration ............................... 220
MP3 - MP3 Player ................................................ 222
Telemetry
Telemetry Data Display ......................................... 225
Programming Examples
Phase Specific Flaps Trimming ............................. 230
Phase Specific Pitch Trimming .............................. 232
Phase Specific Trimming
"RPM Setting" ....................................................... 233
Appendix
Appendix .............................................................. 234
Warning Symbolsand Their Meaning
Always observe the information indicated by
this warning icon, particularly those which
are additionally marked with the following
signal words:
WARNING indicates the potential for serious
injury.
CAUTION indicates possibility of lighter in-
juries.
This icon indicates information that may be
helpful in diagnosing or troubleshooting, es-
pecially when accompanied by the following
signal words:
Note indicates potential malfunctions.
Attention indicates potential damages to
objects.
P
This symbol indicates instructions on the
care and maintenance of the device. Follow-
ing these instructions will help the device re-
main in good functioning condition.
3
Before use
