GRAUPNER mz-24 PRO Programming Manual

INC
RES
DEC
000%
000%
AILE1 AILE2
ON
ACT CTL
NEXT
SW 6
RATE
BACK
LANDING Airbrake
SERVO
Press
The field highlights blue:
INC
RES
DEC
000%
000%
AILE1 AILE2
EIN
ACT CTL
NEXT
SW 6
RATE
BACK
LANDING Brake
SERVO
Press the INC or DEC buttons or the arrow keys
( pq ) to increase/decrease the value within a range
of ±150%:
INC
RES
DEC
+023%
000%
AILE1 AILE2
ON
ACT CTL
NEXT
SW 6
RATE
BACK
LANDING Airbrake
SERVO
Use the same procedure to adjust the other values
for all remaining ailerons, including inboard ailerons.
Press the  RES button to reset the changed value
back to the default.
To bring up the flap setting screen, press the NEXT
button at the right edge of the display. Use the same
procedure described above to adjust all value fields:
INC
RES
DEC
–035%
–034%
INH
ACT CTL
NEXT
ON
RATE
BACK
LANDING Airbrake
SERVO
FLAP1 FLAP2
FLAP3
FLAP4
–045% –045%
When activating the selected control, to prevent sud-
den deflection of the (brake) flaps adjusted, press
the NEXT button at the right of the display to go to
the AIRBREAK display screen. Use the same proce-
dure described above to incorporate a delay for the
deflection of the flaps:
1.2s
AIRBRAKE DELAY
INC
RES
DEC
NEXT
BACK
PHASE 1 Airbreak
SERVO
Tip
To smoothly retract the flaps, use the FUNCTION sub-
menu PHASE to set up a LANDING phasein addition to
the NORMAL phase incorporated with aswitching de-
lay. For the switch, use the same control used to trigger
the braking function.
To save and exit, press the BACK button at the top
left of the display to return to the previous menu.
BACK
SYSTEM
BASE
FUNCTION
Phase
Wing MIX
D/R,EXPO
THR.CRV
Idle LOW
Snap roll
Prog.MIX
Aile diff
Flap MIX
Flap set
TTrainer
Airbrake
Sequence
Logical sw
V-Tail
201
Function menu | Airplane models - brakes
