The SYSTEM menu selection display appears as fol-
lows:
BACK
SYSTEM
BASE
FUNCTION
ST mode
Etc. Set
Warning
Display
MP3
Stick Cali
This menu is transmitter-specific and the submenus
are applicable to all models. However, the Warning
menu options will vary slightly according to certain
model settings.
The TELEMETRY display had no submenu selection.
The screen can differ depending on system settings.
If the Outdoor disp option of the SYSTEM submenu
Display is turned OFF, the TELEMETRY menu se-
lection display appears as follows:
BACK
5.2V
VOLT
5.0V
L-VOLT
3.0 3.0
R
25
6.0 6.0
0 0
70
-20
+26°C
TEMP
- 58dB
- 52dB
T
0020ms
L
075%
S
100%
Q
NEXT
If the Outdoor disp option of the SYSTEM submenu
Display is turned ON, the TELEMETRY menu se-
lection display appears as follows:
RX
-41dB
Receiver
BACK
NEXT
TX
-62dB
VOLT
04.1V
Min V
04.1V
TEMP
+032°C
QUA
100%
STR
100%
L-PACK
2000ms
Refer to the Telemetry section (page 225) for addi-
tional information on telemetry settings and outdoor
display functions.
