GRAUPNER mz-24 PRO Programming Manual

System Warning Display
Additional warnings may be triggered based on pow-
er and signal information, located in the mz-24 PRO
system menu. Press the mz button in the center of
the basic display to access the menu:
000
000
000
000
mz
000%
000%
000
000
BATT TIME 00: 01: 23
MODELLNAME 1
M - 1
PHASE 1
000:00.0
000:00.0
4.2V
0:01:23
TX RX
RX 00.0V
Press
TX VOLT
04
4.2V
AUTO LOAD
RX VOLT
00
00.0V
STRENGTH
00
000%
ESC CUR
00
000.0A
ESC VOLT
00
00.0V
STRENGTH ALARM
BACK
CLR
OFF
OFF
Acoustic warnings will sound and systems requiring
attention will be highlighted in red. In the example
below, the transmitter's supply voltage has reached
the warning threshold:
TX VOLT
04
3.5V
AUTO LOAD
RX VOLT
00
4.9V
STRENGTH
00
000%
ESC CUR
00
000.0A
ESC VOLT
00
00.0V
STRENGTH ALARM
BACK
CLR
OFF
OFF
Stop operating the model as soon as an acute warn-
ing is displayed and attend to the issue before con-
tinuing.
The mz system data display will automatically appear
when the transmitter is turned on and alarm function is
triggered. To stop the mz system display screen from
automatically appearing, touch the ON button at the
top right to change to OFF , and press the BACK
button to save setting.
The red number at the top right of each warning field
shows the number of current warnings; in the prior
example, the warnings generated are at 04. Deleted
this count by pressing the CLR button next to the
back button. All warning counts can be cleared the
same way. With the Strength Alarm, triggered alarms
can be turned off by pressing the ON button under
STRENGTH ALARM to switch it to OFF.
Press the BACK button to exit and return to the ba-
sic display.
CAUTION
!
A STRENGTH ALARM set to the OFF po-
sition will stay off the next time the trans-
mitter is turned on. Manually change the
setting back to ON.
9
Warnings
