Appendix B Connectors and Front End Card Options Overview of Rear Panel Ports and Connectors
© 2012 Harmonic Inc. 184 ProView 7000 v.2.6, Rev. E
GenLock 1 x Genlock synchronization input with single decoder
Genlock feature and connector is optional
BNC, 75 Ω
Analog Audio 1 x Analog audio stereo output (balanced) with single
decoder
2 x Analog audio stereo output (balanced) with dual
decoder
D-Type, 15-pin condensed
Digital Audio
Balanced
1 x Digital audio stereo output (balanced) with single
decoder
2 x Digital audio stereo output (balanced) with dual
decoder
D-Type, 15-pin condensed
CV 1 x Analog video output with single decoder
2 x Analog video output with dual decoder
BNC, 75 Ω
CV MON 1 x Analog video monitoring output with single
decoder2 x Analog video monitoring output with dual
decoder
BNC, 75 Ω
HD/SD-SDI 2 x HD/SD-SDI with embedded audio with single
decoder
4 x HD/SD-SDI with embedded audio with dual
decoder
BNC, 75 Ω
AES/EBU 0 x AES/EBU digital audio output with dual decoder
and dual genlock
2 x AES/EBU digital audio output with single decoder
4 x AES/EBU digital audio output with dual decoder
BNC, 75 Ω
HDMI 1 x HD monitoring interface, Audio 1 (stereo)
embedded with single decoder
HDMI
Management related interfaces
Management External access to the device for control and
monitoring
RJ-45
Control RS-232 interface connector D-Type, 9-pin
GPI General Purpose Interface connector, provides dry
contacts (relays) to drive external alarms
5 x dry contacts – ProView 7100™
2 x dry contacts – ProView 7000™
D-Type, 9-pin –
ProView 7000™
D-Type, 15-pin female
condensed –
ProView 7100™
Power related interfaces
AC Power Socket and
Switch
100–240 VAC 50/60Hz external power supply
connector (for 18AWG three wire cord) and on/off
power switch
Grounding Jackscrew Jackscrew for connecting the grounding cable when
the unit is rack mounted
1. For best performance connect 75Ω terminators on all unused RF ports.
Table B–1: Rear Panel Ports and Connectors
Interface Description Connector Type
