Chapter 2 Quick Start Configuring and Monitoring
© 2012 Harmonic Inc. 22 ProView 7000 v.2.6, Rev. E
To configure the ProView 7000™ using the Front Panel:
1. If the input stream is received from a satellite, navigate
Root > Reception > SAT (no.) > Configuration and configure the receiver parameters
according to your satellite parameters, see 4.1 Configuring the DVB-S/S2 Input Port
Properties for details.
2. If the input stream is received from IP, perform the following to configure the GbE port:
aNavigate Root > GbE > GbE Port (1 or 2) > IP Configuration.
b Configure the IP Address and Subnet Mask.
c Select Apply Port Changes.
d Select Apply Changes.
eNavigate Root > GbE > GbE Port (1 or 2) > Admin Status.
f Set the Admin Status to Up.
gNavigate Root > GbE > Socket Configuration > Socket In > Socket (no.) >
Traffic Parameters.
h Configure the IP Address Type, UDP Port and IP Address if you are using Multicast.
iNavigate Root > GbE > Socket Configuration > Socket In > Socket (no.).
j Configure the Socket De-Jittering Mode, SSM and Socket Admin Status.
3. If the output stream is sent to IP, perform the following to configure the GbE port:
aNavigate Root > GbE > GbE Port (1 or 2) > IP Configuration.
b Configure the IP Address, Subnet Mask and Default Gateway.
c Select Apply Port Changes.
d Select Apply Changes.
eNavigate Root > GbE > GbE Port (1 or 2) > Admin Status.
f Set the Admin Status to Up.
gNavigate Root > GbE > Socket Configuration > Socket Out > Socket (no.).
h Configure the Destination IP Address and the Destination UDP Port.
i Set the Socket Status to Up.
4. If you wish to descramble, you must associate the CAM to the multiplex:
aNavigate Root>CAM>CAM(1–4)>CAM Association.
b Select a multiplex, TS1, TS2, TS3 or TS4.
The descrambling mode default is Selective, you can change the mode to Full.
5. To access the CAM MMI menu, select CAM MMI.
6. Select a DVB-S/S2 input port:
aNavigate Root > Routing and Descrambling > TS (no.) > Input Selection.
b Select an input port for the received transport stream (Options: SAT (1–4), ASI (1–4)).
7. Select Input Type, (Options: MPEG and DVB). This also sets the respective PSI/SI tables for
the output stream.
NOTE: The default option for stream type is DVB. For ATSC systems, set the stream type to MPEG.
