8. To configure the multiplex output:
aNavigate Root > Routing and Descrambling > TS (no.) > Output Selection.
b Select one or more outputs for the received transport stream (Options: ASI (1–2),
Socket (1–4).) The four sockets are virtual and must be associated to a physical GbE
port.
c Select Enable in each output sub-menu that you select.
NOTE: In this mode, stream information is not processed and output bit rate is identical to input bit rate.
dNavigate Root > Routing and Descrambling > TS (no.) > Activation.
e Select Enable.
9. To select a program for descrambling:
aNavigate Root > Routing and Descrambling > TS (no.) > Descrambling.
A list of all input programs received displays.
Program name, program ID, program type and program scrambling state display.
b Select a program for descrambling.
c Select CAM Selection.
d Select CAM 1, 2, 3 or 4 to associate the program to it.
Repeat steps 6 to 9 for each multiplex that you wish to use (1–4).
10. Navigate Root > Decoding > Decoder (no.) > Configuration> Input Selection.
If you only have a single decoder then their is no Decoder (no.) menu.
11. Select a multiplex, 1, 2, 3 or 4, for input.
12. Set the Service Selection Mode:
aNavigate
Root > Decoding > Decoder (no.) > Configuration > Service Selection Mode.
If you only have a single decoder then their is no Decoder (no.) menu.
b Select Program Selection.
Name Id Device
Mode
1BBC ID:4301 TV CAS
2CNN ID:4302 TV CAS
3 IBA 2 ID:4308 AUDIO FTA
4 MI-TV ID:8025 TV FTA
