Chapter 4 Device Configuring Using the Front Panel Configuring the DVB-S/S2 Input Port Properties
© 2012 Harmonic Inc. 37 ProView 7000 v.2.6, Rev. E
■ Modulator Standard – DVB-S and DVB-S2. Selects the L-Band modulation standard.
Options:
❑ DVB-S
❑ DVB-S2
1
❑ Automatic
1
■ MODCOD – DVB-S and DVB-S2. Selects the modulation type and coding rate, according to
the modulation standard selected.
❑ DVB-S options:
•QPSK 1/2
•QPSK 2/3
•QPSK 3/4
•QPSK 5/6
•QPSK 7/8
• Auto – automatic selection of MODCOD
❑ DVB-S2 options:
• VCM
1
– Variable Coding Modulation format / Automatic
1
•QPSK 1/4
1
•QPSK 1/3
1
•QPSK 2/5
1
•QPSK 1/2
•QPSK 3/5
•QPSK 2/3
•QPSK 3/4
•QPSK 4/5
•QPSK 5/6
•QPSK 8/9
• QPSK 9/10
•8PSK 3/5
•8PSK 2/3
•8PSK 3/4
•8PSK 5/6
•8PSK 8/9
• 8PSK 9/10
• 16APSK 2/3
2
• 16APSK 3/4
2
1. Only available with certain hardware configurations, see B.6 Front End Card Features.
2. A license is required for 16APSK modulation. Only available with certain hardware configurations, see B.6 Front End Card
Features.
