Chapter 4: Spectrum X hardware reference
Specification Details
HD
• 1080i @ 25, 29.97 fps
• 720p @ 50, 59.94 fps
HD 3G 1080p @ 50, 59.94 fps
Ultra HD (UHD)
• 2160p @ 50, 59.94 fps, Interleaved, Square Division
• Synchronized 4x 3G playback and record
Table 4-26: Conversion options
Specification Detail
Up conversion Configurable pillarbox, crop, anamorphic, non-linear. EIA-608 captions
translated to EIA-708. Line 21 OP-42 subtitles translated to OP-47
Down conversion Configurable letterbox, crop, anamorphic EIA-608 compatibility bytes
extracted from EIA-708 data to create EIA-608 captions. OP-47 subtitles
translated to line 21 OP-42
Table 4-27: Standard and Enhanced channel conversion
Clip being played
can be any one of:
Format of External
SDI input:
Primary Output
format can be:
Secondary Output
format can then be:
SD SD SD
720p 720p 720p or SD
1080i 1080i 1080i or SD
1080p, 1080i, 720p,
or SD
1080p 1080p 1080p, 1080i, 720p,
or SD
IMPORTANT: For standard or enhanced channel, the format of the External SDI input
must match the video format of the Primary Output and must be referenced aligned.
Table 4-28: UHD channel conversion
Clip being played
can be any one of:
Format of External
SDI input:
Primary Output
format can be:
Secondary Output
format can then be:
UHD-1,1080p, 1080i,
or 720p
UHD-1 (square
division or
interleaved),1080p,
1080i, or 720p
UHD-1 (square
division or
interleaved)
UHD-1 (square
division or
interleaved), 1080p,
1080i, or 720p
IMPORTANT: For UHD channel, the External SDI input must be referenced aligned.
