Harmonic Spectrum X - Spectrum X Specifications

Spectrum X specifications
Spectrum X specifications
Find specifications for the Spectrum X here.
The Spectrum X series can include one or two SDI I/O modules.
NOTE: For video codec and audio format support, see Spectrum Media and Wrapper
Formats.
Table 4-24: Video I/O connectors and channels
Specification Detail
SD: SMPTE 259M
HD: SMPTE 292M,
424M
UHD: SMPTE
ST425-5
8 DIN 1.0/2.3 connectors per SDI I/O card
Note: The SMPTE specifications refer to BNC connectors only. However,
the DIN connectors on the Spectrum X are electrically equivalent to the
specifications.
SMPTE 2022-6
• (Optional) Two 10 Gb copper Ethernet ports
• (Optional) Two 10 Gb fiber optic ports
Standard Channel
(depends on
configuration)
• 1 - 2 video inputs per channel
• 2 - 3 video outputs per channel with independently configurable up/
down/cross-conversion
Enhanced Channel
(depends on
configuration)
• 4 - 6 inputs per channel
• 2 - 4 video outputs per channel with independently configurable up/
down/cross-conversion
UHD channel
(depends on
configuration)
Both SDI cards on the Spectrum X are required to play or record one
channel of UHD
• 8 inputs per channel
• 8 video outputs per channel with independently configurable up/down/
cross-conversion
Input Four SD/HD DIN 1.0 connectors, SMPTE 259M, 292M, 424M One video
input per channel.
Output Four SD/HD DIN 1.0 connectors, SMPTE 259M, 292M, 424M.
Independently configurable up/down/cross conversion
Simulcast Four SD/HD DIN 1.0 connectors, SMPTE 259M, 292M, 424M
Table 4-25: Video I/O: raster
Specification Details
SD
• 525i @ 29.97 fps
• 625i @ 25 fps
121 Spectrum System 8.4 Installation Guide
