Harmonic Spectrum X - MediaStore 5100 and 5000 Series: Drive Carrier LED States

MediaStore 5100 and 5000 series drive carrier components
Drive activity LED
(green)
Drive status LED
(amber)
Associated operator
panel LED
Status
Blink Off None Drive installed and
operational
Solid Blink (1 sec on/1 sec
off)
None SAS identity set
Solid Solid Logical fault (amber) SAS device fault bit
set
Off Solid Module fault (amber) Power control circuit
failure
Solid Blink (3 sec on/1 sec
off)
Logical fault (amber) Failed disk array
MediaStore 5100 and 5000 series: drive carrier LED states
The drive carrier LEDs work in association with the Operator Panel LEDs.
Drive Activity
LED (Green)
Drive Status LED
(Amber)
Associated Operator
Panel LED
Status
Off Off None No drive installed
Blink Off None Drive installed and
operational
Solid Blink
(1 sec on/1 sec off)
None SAS identity set
Solid Solid Logical Fault (Amber) SAS device fault bit set
Off Solid Module Fault (Amber) Power control circuit
failure
Solid Blink
(3 sec on/1 sec off)
Logical Fault (Amber) Failed disk array
195 Spectrum System 8.4 Installation Guide
