Spectrum
™
System
Release 8.4
Installation Guide

Table of Contents

Questions and Answers

  • K
    Kimberly MartinAug 3, 2025
    What to do if a thermal alarm sounds on the Harmonic Spectrum X Server?
    • D
      Dr. Jordan Bates MDAug 3, 2025
      If a thermal alarm sounds on the Harmonic Server, and the Operator Panel Module Fault displays amber, or the Fan Fail LED is lit on one or more PCMs, it indicates that the internal temperature exceeds a pre-set threshold. First, check that the local ambient environment temperature is within the specified limits. Then, inspect the installation for any airflow restrictions at the front or rear of the MediaStore, ensuring a minimum gap of 25 mm at the front and 50 mm at the rear. Also, check for dust build-up and clean as needed. Avoid excessive re-circulation of heated air from the rear to the front, and it is not recommended to use the MediaStore in a fully enclosed rack. If possible, shutdown the MediaStore and investigate the problem before continuing.
  • M
    Monica ParkerAug 8, 2025
    Why are the fans in my Harmonic Server running fast when it's not hot?
    • M
      Michael VanceAug 8, 2025
      If the ambient air temperature is below 25°C, and the fans in your Harmonic Server have increased in speed, it suggests that some airflow restriction may be causing an increase in the internal temperature. The fans automatically increase speed when a thermal threshold is reached. Check the installation for any airflow restrictions at either the front or rear of the MediaStore, ensuring a minimum gap of 25 mm at the front and 50 mm at the rear. Inspect for restrictions due to dust build-up and clean as necessary. Ensure there isn't excessive re-circulation of heated air from the rear to the front. Using the MediaStore in a fully enclosed rack is not recommended. Verify that all blank modules are in place and reduce the ambient temperature.
  • V
    Vanessa WilliamsAug 15, 2025
    How to fix amber Operator Panel Module Fault LED on Harmonic Spectrum X Server?
    • L
      Laurie SalazarAug 15, 2025
      An amber Operator Panel Module Fault LED on the Harmonic Server indicates a power fault. Check that the AC main connection to PCM is live.
  • B
    beckerfeliciaAug 21, 2025
    What does it mean when the Fan Fail LED is illuminated on PCM of Harmonic Server?
    • A
      Amber SmithAug 21, 2025
      If the Fan Fail LED is illuminated on the PCM of the Harmonic Server, it indicates fan failure. Replace the PCM.
  • L
    Linda HallAug 27, 2025
    How to silence the audible alarm on Harmonic Server?
    • S
      Sara EstradaAug 27, 2025
      When the Audible Alarm sounds, pressing the Alarm Silence Button may mute it. If the Alarm Silence Button is not manually operated, the alarm will automatically mute after two minutes.

Summary

Chapter 2 Spectrum System Installation

Spectrum System Environmental and Power Requirements

Details environmental conditions and power requirements necessary for installing a Spectrum system.

Rack Mounting Instructions

Provides guidance on the procedure for rack mounting Spectrum video servers.

Spectrum Racking Requirements

Outlines the specific rack space and safety requirements for mounting Spectrum system components.

Installing Spectrum X Components

Guides the installation of Spectrum X components, including bezel and drives.

Installing MediaCenter Components

Guides the installation of MediaCenter components, including power supplies and drives.

Connecting AC Power

Provides steps for connecting AC power cords to Spectrum system devices, emphasizing order and power sources.

Powering Up

Details the procedure for powering up Spectrum system devices in the specified order.

Chapter 3 Spectrum Firmware Upgrades

Spectrum Firmware Upgrades: Overview

Outlines the order for upgrading Spectrum video server and I/O module firmware.

Upgrading Spectrum Video Server Firmware

Explains how to upgrade Spectrum video server firmware using SystemManager.

Upgrading I;O Module Firmware

Explains upgrading Spectrum I/O module firmware via Properties or Upgrade Firmware pages.

Handling Device Upgrade Failures

Provides instructions for clearing alarms generated by SystemManager after a device upgrade failure.

Chapter 4 Spectrum X Hardware Reference

About the Spectrum X

Describes the Spectrum X capabilities, operating modes, and key features.

Spectrum X Bezel

Details the Spectrum X bezel, which provides power and status indicators for assessing device status.

Spectrum X Status LEDs

Explains the Spectrum X status LEDs for reference, Ethernet connection, and SDI I/O cards.

Spectrum X Front Panel

Describes the Spectrum X front panel components, including drives and control panel.

Spectrum X Rear Panel

Describes the Spectrum X rear panel, providing network, serial, and audio/video I/O connections.

Spectrum X SDI I;O Connectors: Standard Channel Mode

Details Spectrum X SDI I/O connectors and their functionality in standard channel mode.

Spectrum X SDI I;O Connectors: Enhanced Channel Mode

Describes Spectrum X SDI I/O connectors and their specific functionality in enhanced channel mode.

Spectrum X SDI I;O Connectors: UHD Mode

Breakout Cable

Chapter 5 MediaDirector Hardware Reference

About the MediaDirector 2252 B, 2252 B-DS, and 2251 B

MediaDirector Bezel

MediaDirector Status LEDs

MediaDirector 2252 B and 2252 B-DS Rear Panel

MediaDirector Specifications

Provides specifications for MediaDirector products, including SAS, Ethernet, timing, and dimensions.

Chapter 6 MediaCenter 2200 B Hardware Reference

About the MediaCenter 2200 B

MediaCenter 2200 B Bezel

MediaCenter 2200 B Status LEDs

MediaCenter 2200 B and 2200 B-DS Rear Panel

Power Supply LED States

MediaCenter 2200 B Storage

MediaCenter 2200 B Specifications

Lists specifications for the MediaCenter 2200B, including Ethernet ports and SAS connections.

Chapter 7 MediaPort 7000 Series Hardware Reference

About the MediaPort 7000 Series

MediaPort 7000 Bezel

MediaPort 7000 Rear Panel

Serial Control Connections for a MediaPort 7000 and a ChannelPort

MediaPort 7000 Module Specifications

Provides specifications for MediaPort 7000 modules, including video I/O, conversion, and raster formats.

Chapter 8 ChannelPort Module Hardware Reference

About the ChannelPort

About Enhanced Channel Mode

ChannelPort 8100 Channel Mode Configurations

ChannelPort 8200 Channel Mode Configurations

ChannelPort Module Rear Panel

License Options

ChannelPort Specifications

Provides specifications for ChannelPort modules, including video I/O, conversion, and raster formats.

Chapter 9 MediaStore 5100 and 5000 Series Hardware Reference

About the MediaStore 5100 Series

About the MediaStore 5000 Series

MediaStore 5100 and 5000 Series Front Panel

MediaStore 5100 and 5000 Series Disk Carrier Module

MediaStore 5100 and 5000 Series Drive Carrier Components

MediaStore 5100 and 5000 Series: Drive Carrier LED States

MediaStore 5100 and 5000 Series Operator Panel Components

MediaStore 5100 and 5000 Series Rear Panel

MediaStore 5100 Series I;O Module Components

MediaStore5100: I;O Module Status LEDs

MediaStore 5000 Series I;O Module Components

MediaStore5000 Series: I;O Module Status LEDs

MediaStore 5100 and 5000 Series Power Cooling Modules (PCMs)

MediaStore 5100 and 5000 Series: Power Cooling Module Status LEDs

MediaStore 5100 and 5000 Series RAID Configurations

MediaStore5100 and 5000 Series Troubleshooting and Maintenance

Provides guidance on troubleshooting and maintaining MediaStore 5100 and 5000 series.

Dealing with Hardware Faults

Provides precautions and procedures for dealing with hardware faults in MediaStore.

Audible Alarm States

Troubleshooting Subsystem Recognition Problems

Troubleshooting Thermal Monitoring and Control Faults

Overview of Proactive Drive Alarming and Removal

About Bad-Block Auto-Repair

MediaStore5100 and 5000 Series Specifications

Lists specifications for MediaStore 5100 and 5000 series units.

Chapter 10 MediaStore 7200 Series Hardware Reference

About the MediaStore 7200 Series

Front Panel Components

Control Panel Indicators

Disk Drive LED Indicators

Rear Panel Components

Power Supply Unit LED Indicators

MediaStore 7200 Series Specifications

Lists specifications for the MediaStore 7200, including interface, capacity, and dimensions.

Appendix B Safety and Regulatory Compliance Information

Important Safety Instructions

Reviews important safety guidelines for operators and service personnel regarding product use and safety.

Safety Symbols & Safety, Warning & Caution Instructions

Electromagnetic Compatibility Notices - Class A

Product Regulatory Compliance

Product Environmental Compliance

Waste Electrical and Electronic Equipment (WEEE)

Harmonic Spectrum X Specifications
