Chapter 9: MediaStore 5100 and 5000 series hardware reference
About drive start up
Unless otherwise selected during installation, all drives in the MediaStore will automatically start their
motors upon power-up. If this has not occurred, there may be a power problem (an alarm and power fault
indication would normally be active).
Note that if there is only one Power Cooling Module present, the drive motors will spin up in a delayed
sequence.
Each drive carrier incorporates a green LED and an amber LED. In normal operation, the green LED will
be ON and will flicker as the drive operates.
Related information
MediaStore 5100 and 5000 series disk carrier module on page 193
MediaStore 5100 and 5000 series RAID configurations
Refer to the available RAID configurations for the MediaStore 5100 and 5000 series.
MediaStore 5100 series RAID configurations
Drive Size # of Drives RAID Set Usable Storage
300 GB 24 3 (6+2) 5.23 TB
600 GB 24 3 (6+2) 10.46 TB
1.2 TB 24 3 (6+2) 20.95 TB
MediaStore 5000 series RAID configurations
The MediaStore 5000 series is available in either 16 or 24 drive configurations.
Drive Size # of Drives RAID Set Usable Storage
16 2 (6+2) 3.49 TB300 GB
24 3 (6+2) 5.23 TB
16 2 (6+2) 6.98 TB600 GB
24 3 (6+2) 10.46 TB
16 2 (6+2) 10.47 TB900 GB
24 3 (6+2) 15.71 TB
16 2 (6+2) 13.97 TB1.2 TB
24 3 (6+2) 20.95 TB
206
