Chapter 8: ChannelPort module hardware reference
Key Component Description
14 Status/Wink LED The Status/Wink LED, on the bottom, is blue to
indicate power is ON. This LED can show the
following states:
• Blue, solid: Indicates the unit is powered on.
• Off: Indicates the unit is powered off.
• Blue, blinking: Indicates wink state is on.
For information on changing the wink state,
refer to “Changing the ChannelPort wink state”
in the Harmonic SystemManager User Guide.
15 GPIO Connector This connector can be used for player or
graphics control, or for EAS connection. See
“GPIO connector signal assignments” for signal
assignments.
16 RS-422 Port and LEDs Use this connector (RJ-45) for RS-422 serial
control. The LED at the top left of the port
indicates channel activity.
17 Gigabit Ethernet Port Not applicable for systems running 8.4 and later
software; only systems running 8.3.x.x and earlier
software use this port.
18 Gigabit Ethernet Port Used only in MediaPort 7000.
Related information
About MediaPort 7000 and ChannelPort timing on page 156
GPIO/RS-422 connector signal assignments on page 181
ChannelPort 8200 rear panel: Standard Channel mode
Review to the diagram and the table for details on the rear panel component functionality when
theChannelPort 8200 is in Standard Channel mode.
NOTE: Connections 1 - 8 on ChannelPort 8200 modules use DIN 1.0/2.3 connectors.
178
