Chapter 10
MediaStore 7200 series hardware reference
The MediaStore 7200 series is a 4-rack unit network storage device that employs Serial-attached SCSI
(SAS) host bus adapters (HBA) to connect to the MediaCenter 2200B via SAS cables.
• About the MediaStore 7200 series
• About the file system configuration for MediaCenter 2200B with MediaStore 7200
• Front panel components
• Control panel indicators
• Disk drive LED indicators
• Rear panel components
• Power supply unit LED indicators
• MediaStore 7200 series specifications
About the MediaStore 7200 series
You can connect one MediaStore 7200 series to the MediaCenter 2200B via SAS to provide additional
storage.
The MediaStore 7200 series includes the following features:
• 12 or 24 disk drive capacity, all contained in a 4 RU chassis. All drives install from the front of the
chassis. All power supplies and I/O modules install from the rear.
• Chassis with front panel Operators Panel, including clear status indicators and audible failure alarms.
• Two hot swappable AC Power Cooling Modules (PCMs) with integral cooling fans.
• Hard Disk Drive Carrier Modules and associated dummy carrier modules for blank drive slots.
• Hot-swappable high-performance 2, 4, or 6 TB SAS hard disk drives.
• Serial-attached SCSI (SAS) connections.
NOTE: There are no user-serviceable parts on the MediaStore7200 series.
Harmonic provides either 1 meter or 3 meter SAS cables to connect the MediaStore 7200 to the
MediaCenter.
