Chapter 7: MediaPort 7000 series hardware reference
Product ID Description
AUTO-EXPORT Auto-export to Harmonic MediaGrid license for all channels of the
MediaCenter and MediaDirector respectively.
MediaPort 7000 module specifications
The MediaPort 7000 series chassis can accommodate two modules.
NOTE: For video codec and audio format support, see Spectrum Media and Wrapper
Formats.
Table 7-5: Video channels
Specification Detail
Video channels Each module provides two bi-directional channels
Table 7-6: Video I/O
Specification Detail
SD: SMPTE 259M 75 ohm BNC female connector
HD: SMPTE 292M Single video input per channel. Dual video outputs per channel with
independently configurable up/down/cross-conversion.
Table 7-7: Up Conversion
Specification Detail
Up conversion Configurable pillarbox, crop, anamorphic. EIA-608 captions translated to
EIA-708. Line 21 OP-42 subtitles translated to OP-47
Table 7-8: Down conversion
Specification Detail
Down conversion Configurable letterbox, crop, anamorphic EIA-608 compatibility bytes
extracted from EIA-708 data to create EIA-608 captions. OP-47 subtitles
translated to line 21 OP-42
Table 7-9: SD-SD Aspect Ratio Converter (ARC)
Specification Detail
RP-186 AFD
SMPTE-2016, ATSC
A/53
• 16:9 SD to 4:3 Letterbox (Vertical Decimation)
• 16:9 SD to Full Screen (Horizontal Interpolation)
• 16:9 SD to Crop 14:9 (Vertical Decimation, Horizontal Interpolation)
162
