Chapter 4: Spectrum X hardware reference
Specification Detail
EIA-708 Digital caption data preserved on record and inserted on playout.
Onboard Closed
Caption Insertion
Onboard Closed Caption Insertion available as licensed feature; Cheetah,
NCI, and SCC are supported file types.
Onboard subtitle Insertion
OP47a
SMPTE-2031
Onboard Subtitle Insertion available as licensed feature; STL, PAC, and
890 are supported file types
Ancillary Data
VBI Up to 6 lines (configurable) preserved. Line 21 caption data saved
automatically
VANC Up to 6000 bytes (configurable) preserved per frame
Reference
Analog black with
color burst
Optionally, Precision Time Protocol (SMPTE ST 2059) is supported with
the 10Gb I/O module and 2022-6 license.
Table 4-35: Safety
Specification Detail
UL 60950-1 2nd
Edition
CSA C22.2
Information Technology Equipment - Safety - Part 1: General
Requirements
Table 4-36: Dimensions
Model Weight (including rack rails) L x H x W (bezel attached,
rack mountable per EIA-310
specification)
Spectrum X with two SDI I/O
cards, four drives
37.5 lbs 30.25" x 1.7" x 17.25"
Spectrum X with one SDI I/O
card, four drives
36.6 lbs 30.25" x 1.7" x 17.25"
Spectrum X with two SDI I/O
cards, no drives
32.2 lbs 30.25" x 1.7" x 17.25"
Spectrum X with one SDI I/O
card, no drives
31.3 lbs 30.25" x 1.7" x 17.25"
Table 4-37: Spectrum X power
Specification Detail
Voltage 90 to 132V and 180 to 264V
124
