MediaCenter 2200B specifications
Table 6-5: Serial Attached SCSI (SAS)
Specification Details
MediaCenter 2200B 1 four-port mini SAS HD connector (SFF-8644)
MediaCenter 2200B-
DS
2 four-port mini SAS HD connectors (SFF-8644)
Table 6-6: MediaPort Ethernet array
Specification Details
Private 1 Gb
Ethernet
10 ports available for MediaPort/ChannelPort/Spectrum X connectivity.
Table 6-7: Reference
Per MediaPort/
ChannelPort/
Spectrum X/
The MediaCenter can support multiple timing standards on a single
system. Reference is handled by MediaPorts independently.
Table 6-8: Dimensions
Weight (including rack rails) L x H x W (bezel attached, rack mountable
per EIA-310 specification)
64.5 lbs 30.75" x 3.5" x 17.25"
Table 6-9: MediaCenter 2200B power
Specification Detail
Power (max) 440 W
Voltage 90 to 132V and 180 to 264V
Frequency 47-63Hz
