Chapter 7: MediaPort 7000 series hardware reference
Table 7-26: Video bit rate
Specification Detail
600 Kbps – 3.0 Mbps User configurable
Table 7-27: Chroma sampling
Specification Detail
4:2:0
Table 7-28: Audio encoding
Specification Detail
AAC-LC 0-8 two-channel pairs (up to 16 channels)
Table 7-29: Audio bit rate
Specification Detail
64, 96, or 128 Kbps Per pair
Table 7-30: HD encoded frame size
Specification Detail
640x360 or 432x240 User configurable
Table 7-31: SD encoded frame size
Specification Detail
25 fps: 352x288, 320x240 29.97 fps:
352x240, 320x240
User configurable
Table 7-32: Wrapper
Specification Detail
MXF Op1a low-latency, QuickTime
self-contained
Table 7-33: Ancillary data
Specification Detail
AFD, timecode, closed captions Stored as unregistered SEI
Table 7-34: Timecode burn-in
Specification Detail
Within frame or below it Position selectable by user
