MediaStore 5100 and 5000 series operator panel components
Key Component Descriptions
7 Audible Alarm
(behind panel)
The Audible Alarm can be activated for a variety of
reasons. Refer to “MediaStore 5100/5000 series audible
alarms” for additional details.
8 Thermal Sensor
(behind panel)
The Operator Panel Thermal Sensor is on the outside the
MediaStore and connects to another thermal sensor on
the midplane of the MediaStore. This external Thermal
Sensor sends input to the MediaStore about its external
operating ambient temperature. Its other function is to cause
a warning signal to be generated by the SAS when there
is a break in this sensor's connection to the MediaStore
midplane. Refer to “MediaStore 5100/5000 series audible
alarms” for details.
The operator panel LEDs work in association with other LEDs and alarms on the MediaStore.
Table 9-3: MediaStore 5100/5000 series operator panel LEDs and alarms
System
Power,
(green or
amber)
Module
Fault
(amber)
Logical
Fault
(amber)
LED
Display
Associated
LEDs/
Alarms
Status
Solid Solid On On Operator panel power
on, test state
Solid Off Off 5V standby power
present, overall power
failed or switched off
Solid Off Off Power on, all functions
good
Solid Solid PCM fault
LEDs,
fan fault
LEDs
Any PCM fault, fan
fault, over or under
temperature
Solid Solid I/O
module
LEDs
Any Storage Bridge Bay
(SBB) module fault
Solid Solid No
module
LEDs
MediaStore logical fault
Solid Blink Module
status
LED on I/
O module
Invalid or mixed SBB
module type installed,
I
2
C bus failure, EBOD
VPD configuration error.
197 Spectrum System 8.4 Installation Guide
