Chapter 10: MediaStore 7200 series hardware reference
Key Component Description
2 Control panel Displays power, temperature, fan, and system
status LED indicators.
3 System alarm mute
button
Unused (alarm disabled).
4 Bezel LED control
connector
Powers the light bar on the bezel.
Drive numbering
Drives are numbered from 1-24, starting with the top left drive.
Figure 10-2: Drive slot numbers
