Commissioning
Fig. 19: Rolling the incubator down
over metal rails
Unloading from the pallet, HettCube
200/200 R
1
2
Fig. 20: Front beam
1 Fastening screws
2 Front beam
21
1
2
Fig. 21: Mounting metal rod
1 Metal rods
2 Washers
1
Fig. 22: Front wooden beam on the
oor
1 Front wooden beam
5. Roll the incubator carefully down from the wooden pallet using
the metal rails.
1. Remove the front wooden beam.
2. Stick the washers included in delivery onto the metal bars and
scr
ew the metal bars into the two holes on the rear panel.
3. Put the front wooden beam about 50 centimetres in front of the
wooden pallet.
