9.2 Using a PC Card
148
About file types and saving
Settings file
Manual save Auto-save
_______
Measured data file
Manual save Auto-save
(Binary format: Time-series, Event data)
Saving when the operation status is
[RECORDING]:
(Auto-save settings required)
❖ Measured data files Auto-
save (binary format) settings
(page 152)
(Text format: Time-series, Event list data)
Saving when the operation status is
[RECORDING]:
(Auto-save settings required)
❖ Auto-save measured data file
(text format) settings (page
154)
(Text format: Event waveform data)
_____________
Screen copy file
Manual save Auto-save
Saving is possible when the operation status is [SETTING],
[RECORDING], [ANALYZING].
Saving when the operation status is
[RECORDING]:
(Auto-save settings required)
PC-CARD
❖ Manual saving of the settings files (page 149)
When the operation status is [SETTING]:
When the operation status is [ANALYZING]:
SAVE
SETUP FILE
PC-CARD
SAVE
PC-CARD
BINARY FIL
E
(Saves all data in the internal memory, including settings files.)
❖ Manual saving of the measured data files 1 (Binary format:
all data) (page 149)
When the operation status is [ANALYZING]:
SAVE
PC-CARD
❖ Manual saving of the measured data files 2 (Text format:
time-series/ event list/ flicker data) (page 150)
When the operation status is [ANALYZING]:
TEXT FILE
SAVE
TEXT Select
RETURN
LIST
❖ Manual saving of the measured data files 3 (Text format:
event waveform data) (page 152)
WaveTextSave
When the operation status is [ANALYZING]:
