Hioki MEMORY HiLOGGER LR8450 User Manual

245
Conguring and Establishing a LAN Connection
Conguring LAN settings
To communicate with the instrument over the LAN, congure the following settings:
• [DHCP server]
If [DHCP server] is set to [ON], the instrument will automatically acquire the IP address and
subnet mask.
OFF

Disables the DHCP function.
ON Enables the DHCP function.
• [Host name]
Specify the instrument’s hostname.
String of up to 12 single-byte characters (example: LOGGER)
• [IP address]
Set the instrument’s IP address.
_._._._ (_: 0 to 255) (example: 192.168.1.2)
• [Subnet mask]
_._._._ (_: 0 to 255) (example: 255.255.255.0)
• [Port number]
Set the number of the TCP/IP port used by the instrument.
The last digit cannot be set as it is used by the instrument’s rmware.
____ (_: 0 to 9) (example: 880X)
• [Gateway]
If [DHCP server] is set to [ON], the gateway will be set automatically.
OFF

, ON
• [Gateway IP]
If [Gateway] is set to [ON], set the IP address of the device that will serve as the gateway.
_._._._ (_: 0 to 255)
• [DNS]
Select whether to use DNS.
OFF

, ON
• [DNS IP]
If [DNS] is set to [ON], set the DNS server’s IP address.
_._._._ (_: 0 to 255)
Communicating with a Computer (PC)
HIOKI LR8450A964-03
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Hioki MEMORY HiLOGGER LR8450 Specifications

General

Storage Media	SD card (up to 32 GB)
Measurement Types	Voltage, Temperature, Resistance, Strain, Pulse, Logic
Sampling Rate	1 ms to 1 hour
Interface	LAN, USB, SD card slot
Power Supply	100 to 240 V AC, 12 V DC
Resolution	16-bit
Voltage Range	±10 mV
