Hioki MEMORY HiLOGGER LR8450 User Manual

271
Sending Data Using the FTP Client
4
Click [Inbound Rules] on the left pane,
right-click [FTP server (FTP Tra󰀩c-In)],
and click [Properties] in the shortcut
menu.
The [FTP Server (FTP Tra󰀩c-In)
Properties] dialog box will be displayed.
5
Select [Enabled] on the [General] tab
and then click [OK].
6
Verify that [FTP Server (FTP Tra󰀩c-
In)] is enabled and click [×] (the [Close]
button).
Communicating with a Computer (PC)
HIOKI LR8450A964-03
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Hioki MEMORY HiLOGGER LR8450 Specifications

General

Storage Media	SD card (up to 32 GB)
Measurement Types	Voltage, Temperature, Resistance, Strain, Pulse, Logic
Sampling Rate	1 ms to 1 hour
Interface	LAN, USB, SD card slot
Power Supply	100 to 240 V AC, 12 V DC
Resolution	16-bit
Voltage Range	±10 mV
