300
2. Recording
Recording mode Normal
Recording intervals 1 ms*, 2 ms*, 5 ms*, 10 ms, 20 ms, 50 ms, 100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s,
20 s, 30 s, 1 min., 2 min., 5 min., 10 min., 20 min., 30 min., 1 h
*: Setting available only when using a module with data refresh intervals including 1 ms.
Data refresh interval Automatically- or user-selected value per module
Automatically-selected value:
The optimal data refresh interval is automatically selected
based on the recording interval setting.
Repeat recording
On:
Recording resumes after recording stops (due to stop trigger conditions or the
completion of measurement for the set recording time). Recording repeats until the
STOP key is pressed.
Specied time/
continuous
The recording time is set in days, hours, minutes, and seconds.
The time can be set up to the maximum capacity of the internal
Continuous Recording is performed once until it is stopped.
exceeded, the memory will be overwritten.
Waveform recording The last 256 M data points (when recording 1 analog channel; if recording n channels,
256 M/n
1
The numerical expression of the number of channels (n)
n = (Number of analog channels) + (number of pulse channels) × 2
+ (number of logic channels) × 1
+ (number of waveform calculation channels) × 4
+ (number of CAN channels*
2
) + 26*
3
*1: CAN channel alarm source data cannot be recorded.
*2: Calculated as 2 channels when using 32 bits or 4 channels when using 64 bits.
*3: Added when the alarm source setting is enabled.
Backup of recorded
data
None
