Hioki MEMORY HiLOGGER LR8450 User Manual

46
Conguring CAN Settings
6
(If operating in [Measured value output mode])
Select whether to output measured values under [Measured value output].
Settings controlling measured value output are congured with the CAN Editor. On the LR8450,
you can select whether to output measured values overall.
OFF Disables CAN Unit measured value output.
ON

Enables CAN Unit measured value output.
7
Send the CAN Unit settings from the LR8450 to the CAN Unit with [Apply].
Even if you don’t send the settings, they will be sent when measurement starts.
8
Press the ENTER key while [ID search] is selected.
The instrument will search IDs received by the target CAN Unit and display a dialog box.
HIOKI LR8450A964-03
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Hioki MEMORY HiLOGGER LR8450 Specifications

General

Storage Media	SD card (up to 32 GB)
Measurement Types	Voltage, Temperature, Resistance, Strain, Pulse, Logic
Sampling Rate	1 ms to 1 hour
Interface	LAN, USB, SD card slot
Power Supply	100 to 240 V AC, 12 V DC
Resolution	16-bit
Voltage Range	±10 mV
