Hioki MEMORY HiLOGGER LR8450 User Manual

61
Using the Scaling Function
Scaling settings during integration measurement
You can use the scaling function to convert the integrated pulse count to the measurement target’s
physical properties (watt hours, volt-amperes, etc.) and then display or record the result.
The pulse output device will have predetermined physical quantity that corresponds to 1 pulse or
a number of pulses that corresponds to a value of one in the basic units (for example, 1 kWh, 1 L,
1 m
3
).
> >
2
2
3
3
1
1
1
Select the scaling display method.
OFF

Does not use the scaling function.
Decimal Displays converted values as decimals.
Exponent Displays converted values as exponents.
2
Enter the post-conversion unit (up to 7 single-byte characters).
See “Text entry method” (p. 10).
Settings and Operation
HIOKI LR8450A964-03
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Hioki MEMORY HiLOGGER LR8450 Specifications

General

Storage Media	SD card (up to 32 GB)
Measurement Types	Voltage, Temperature, Resistance, Strain, Pulse, Logic
Sampling Rate	1 ms to 1 hour
Interface	LAN, USB, SD card slot
Power Supply	100 to 240 V AC, 12 V DC
Resolution	16-bit
Voltage Range	±10 mV
