The field wire must be connected with one of the following OUT pins
(together with the branch). One of the OUT pins can be used for
connecting the return field wire.
n Two DO channels with a two pin branch
n Three DO channels with a three pin branch
Universal Analog Input Module (UAI) Wiring
The Universal Analog Input Module has eight inputs, which can
include any combination of the following input types: RTD, TC, Ohms,
Millivolt, Volt, or Milliamp. Figure shows wiring examples of each of
the analog input types. An example of wiring for eight TC inputs is
given in Analog Input Wiring - Eight TCs section.
Specifications for this module, see Universal Analog Input Module
(UAI) section.
ATTENTION:
To indicate sensor failure the Analog Input software will output
a warning if thermocouple resistance > 80 ohms. Use
appropriate gauge wiring to prevent inaccurate failure
warnings.
Table 5-20: Typical Thermocouple resistance in Ohms per Double Foot @ 68 degrees F
AWG
No.
Diameter
inches
Type
K
Type
J
Type T
Type
E
Type S
Pt/
PT110
Type R
Pt/
PT113
Type
W5/
W26
Type
W/
W26
10 0.102 0.058 0.034 0.029 0.069 0.018 0.018 0.023 0.020
12 0.081 0.091 0.054 0.046 0.109 0.028 0.029 0.037 0.031
14 0.064 0.146 0.087 0.074 0.175 0.045 0.047 0.058 0.049
16 0.051 0.230 0.137 0.117 0.276 0.071 0.073 0.092 0.078
18 0.040 0.374 0.222 0.190 0.448 0.116 0.119 0.148 0.126
20 0.032 0.586 0.357 0.298 0.707 0.185 0.190 0.235 0.200
24 0.0201 1.490 0.878 0.7526 1.78 0.464 0.478 0.594 0.560
26 0.0159 2.381 1.405 1.204 2.836 0.740 0.760 0.945 0.803
