Analog Output Module (4 Channels) Wiring
An example of Analog Output Module wiring is shown below.
Isolation
The four outputs are isolated from each other.
Shield Grounding
Shields must be grounded as described under Shield Grounding at
the beginning of this section.
CAUTION: Hazardous voltages exist at terminal blocks.
Using switches at field devices disconnect the field wiring form
power sources before servicing.
Failure to comply with these instructions could result in death or
serious injury.
Figure 5-53: 4 channel Analog Output Wiring Diagram
140
