Digital Input Module (32 Channels)-DC Voltage Type
Wiring
The 32-point DC Digital Input module below provides two groups of
16 inputs, each with a pair of terminals for connection to common.
DC power applied between the common terminal and an input cause
the input to turn ON. A green LED on the module provides indication
of an ON state. Logic in the controller allows the state to be inverted
when necessary.
Requires Low Voltage Euro style 36-terminal terminal block.
Figure 5-38: 32 point DC Input Module Wiring
