Digital Output Module (32 Channels)-DC Voltage
Type Wiring
The DC digital Output module provides 32 externally powered outputs
in 2 groups of 16 (Figure below). The outputs are high side switching
(current sourcing) type. Over-current protection is provided for each
channel, in 4 groups of 8 channels. In case of short circuit for any
output channel, that whole group of 8 is switched off. Power cycling is
not required to reset the module. A green LED on the module
provides indication of an ON state for each output. It can be used with
Low Voltage Euro style 36-terminal terminal block.
Figure 5-41: 32 point DC Output Module Wiring
