Honeywell ControlEdge 900 platform

CHAPTER
5
CONTROLEDGE 900 COMMON REFERENCE
INFORMATION
This section is applicable to both UOC and PLC systems and provides
the following information:
n Installation
n Wiring and cabling planning
n Maintenance
n Diagnostics and Troubleshooting
n Special Condition of Use and Approved Standards
Installation
The topics covered in this chapter are:
n See "Rack options" below for more information.
n See "Rack Types" on page55 for more information.
n See "Rack installation" on page64 for more information.
n See "Power Supply" on page77 for more information.
n See "Environmental considerations" on page81 for more
information.
n See "ControlEdge 900 I/O " on page87 for more information.
n See "Terminal block styles" on page100 for more information.
n See "Terminal Block-to-Field (Signal) Wiring" on page106 for
more information.
Rack options
I/O racks are available in 4-slot, 8-slot, and 12-slot versions and can
be utilized to house either a controller and I/O or as an I/O expansion
rack containing EPM and I/O.
Both 8-slot I/O rack and 12-slot I/O rack have two types of racks:
