Appendix A - Installing RTP
Twisted Pair Number Module TB Position RTP J1 Plug Connector Color
4 9 17 Black
10 16 Blue
5 11 15 Black
12 14 Yellow
6 14 12 Black
15 11 Brown
7 16 1 Black
17 2 Orange
8 19 4 Red
20 5 White
9 3 8 Red
8 18 Green
10 13 13 Red
18 3 Blue
RTP Internal schematic (Applies to UIO, 4 AO, 16 DI and 8 DO)
See the figure below for RTP Internal schematic (Applies to UIO, 16 DI and 8 DO).
Figure A-12: RTP Internal schematic of (Applies to UIO, 4 AO, 16 DI and 8 DO)
220
