Component
Type
Comments
EPMs while its ETH2 port is left disconnected. Before it is inserted into its
slot, the 100x rotary switch on the EPM board must be set to indicate
the type of network connectivity in use. This is done by setting it to
position 4. The IP address of the EPM is assigned by the UOC CPM
based on the module number set on the 10X and 1x rotary switches.
These switches must also be set before the EPM is inserted into its
slot.
Unmanaged
Switches
900 I/O racks with EPM gateways have been qualified to
communicate with UOC through unmanaged switches. EPMs may not
be connected through managed switches.
Stratix
Switches
EIP I/O, devices and PLCs may be connected to UOC through
qualified, Stratix managed switches. For further information on how to
deploy and configure Stratix switches, see EtherNet IP User's Guide_
EPDOC-X399-en-510A.pdf.
Following section provides information about installing racks, EPM,
power supply and so on.
Table 4-1: Reference for installing racks, EPM, power supply and so on
Components Reference section
Racks For information about options and types of racks, see the sections
Rack Options and Rack Types. For information about installing
Racks, see the section Rack Installation.
EPM For information about installing EPM, see the section Expansion
Processor Module.
Power Supply For information about connecting to AC or DC power supply, see
the section Power Supply.
Configuration For information about configuration, refer to the Software
Configuration Guide.
Environmental For information about environmental consideration to be taken
care, see the section Environmental Considerations.
Hardware configuration of UOC-CPM
For more information refer to the UOC User’s Guide (PLC to UOC
conversion).
