Appendix A - Installing RTP
RTP Cable wire positions and colors(Applies to 16 AI, 32 DI and
32DO)
See the table below for RTP Cable wire positions and colors(Applies to 16 AI, 32
DI and 32 DO) :
Twisted Pair Number of Cable A Module TB Position RTP J1 Plug Connector Color
1 1 6 Black
2 7 Red
2 4 9 Black
5 10 White
3 6 20 Black
7 19 Green
4 18 17 Black
17 16 Blue
5 18 15 Black
17 14 Yellow
6 10 12 Black
11 11 Brown
7 12 1 Black
13 2 Orange
8 15 4 Red
16 5 White
9 3 8 Red
8 18 Green
10 9 13 Red
14 3 Blue
Table A-4: RTP A Cable wire positions and colors (Applies to 16 AI, 32 DI and 32 DO)
