Redundant Controller Rack
Redundant Controller Rack is shown in the following figure.
Figure 5-3: Redundant Controller Rack Components
As indicated in Redundant Controller Rack Components section, the
Redundant Controller Rack includes:
Item Description
1 Redundant Controller Rack
2 Redundant Switchover Module Slot Filler
3 Two CPMs (Redundant Primary and Secondary)
4 Two Power Supplies
58
