Table 5-2: Rack size
I/O Slot Option Height Width Depth Comments
4-slot 5.4" 10.5" 6.0" Rear mounting plate extends
height to 6.9” (175mm)
8-slot 5.4" 16.5" 6.0"
8-slot with redundant
power supply
5.4" 20.9" 6.0"
12-slot 5.4" 22.5" 6.0"
12-slot with redundant
power supply
5.4" 26.9" 6.0"
Redundant Controller
Rack
5.4" 10.3" 6.0"
1-slot 5.4" 5.9" 6.0"
Recommended vertical spacing of racks, which is required for rack
ventilation and for routing wires, is shown in Vertical spacing of racks
(all models).
Figure 5-8: Vertical spacing of racks (all models)
