Appendix A - Installing RTP
Overview of RTPs
The Remote Termination Panel (RTP) provides an easy way to connect the
ControlEdge 900 controller to the field wiring. The RTP integrates some of the
typical externally connected components, reducing wiring and setup time. It also
minimizes the need for multiple wires under a single screw connection by
expanding the connectivity of the shared terminals of the I/O modules.
There are three RTP types:
n 900RTA-L001 for UAIî
n 900RTS-0001 for UIO, AI, AO, DI and DO
n 900RTR-H001 for Relay Output
The relationship of modules, terminal blocks and their RTP components are listed
below:
Table A-1: Module and RTP Matching Table
I/O Module
Terminal
Block
(Euro)
Terminal
Block
(Barrier)
RTP
RTP
Cable
RTP required per module
(only for RTP not for Cable)
UIO (900U01-
0100)
900TEK-
0200
900TBK-
0200
900RTS-
0001
900RTC-
H2xx
1
UAI (900A01-
0202)
900TEK-
0200
900TBK-
0200
900RTA-
L001
900RTC-
L2xx
1
DI24 (900G32-
0101)
900TCK-
0200
N/A 900RTS-
0001
900RTC-
34xx
2
DI110/220
(900G03-0202)
900TER-
0200
900TBR-
0200
900RTS-
0001
900RTC-
H2xx
1
DO24(900H32-
0102)
900TCK-
0200
N/A 900RTS-
0001
900RTC-
34xx
2
DO110/220
(900H03-0202)
900TER-
0200
900TBR-
0200
900RTS-
0001
900RTC-
H2xx
1
DO 8 CH
(900H01-0202)
900TER-
0200
900TBR-
0200
900RTR-
H001
900RTC-
H2xx
1
HLAI 16 CH
(900A16-0103)
900TCK-
0200
N/A 900RTS-
0001
900RTC-
34xx
2
