Digital Output Module (8 Channels) - AC Voltage
Type Wiring
The AC Output Module provides eight output circuits. Each output is
isolated from the other outputs. An example of AC output wiring is
shown below. Specifications for this module, see Digital Output
Module (8 Channels)-AC Voltage Type section.
Output Loading
Voltage: 85 to 240 V AC
Maximum per output: 2.0 A resistive load
Maximum per module: 8.0 A
TIP:
When exceeding 1.0 A per output, it is recommended (but not
