n Update Rate: 6 ms Maximum
n Switching current: 2.6mA norminal
n Galvanic Isolation: Between Field wiring (input or output) and
Module
n Power supply Loading:
l 5 V; 130 mA maximum
l 24v; 40 mA maximum
Digital Output Module (8 Channels) - AC Voltage
Type
DO AC Voltage type module supports:
l Channel Density: 8 Channels
l Output Type: Triac (Zero switching voltage)
l Input voltage range: 85 V AC to 240 V AC.
l Isolation: Galvanic ally isolated per Channel to channel and
channel to rack.
l Transient Overload Voltage Protection
l Maximum Load Current: 2 A per channel and 8 A max. per module
(Resistive load)
l OFF to ON Response Time*: 3 ms + 0.5 line cycle max
l ON to OFF Response Time*: 3 ms + 0.5 line cycle max
l Power Supply Loading: 5 V: 220 mA max and 24V: 0 mA
l Per channel Field-replaceable fuse support
l 20 pin EURO style terminal block
l RTP support. For more information, see Using an RTP to field
wiring the 8 Point AC DO section.
TIP:
*Excluding controllers scan time and excluding transmission
time from module to rack.
Digital Output Module (32 Channels) - DC Voltage
Type
The Digital Output Module – DC Voltage Type is current sourcing type
module.
DO DC Voltage type module supports:
