81
Module
A: Enter
Quantity
B: Max
Current
@ 5V
C: Max
Current
@ 24V
D:
Calculate
5V current
(D = A * B)
E:
Calculate
24V
current (E
= A * C)
Total mA
@ 5V - ( )
Total mA @
24V - ( )
* The field device is powered by external 24 V power supply. For more information,
see Universal Input/Output Module on section.
Environmental considerations
The product is only used indoors. The CPM must be mounted in
suitable equipment enclosures. That is, all components such as the
Redundant Controller Rack and I/O rack manufactured by Honeywell
must be mounted in approved furniture designed for industrial
applications.
Consideration should be given to the installation so that the potential
for the build-up of static electricity is minimized or eliminated.
Table 5-8: Environmental specifications
Item Description
Operating temperature 0 to 60 °C
Storage and transportation
temperature
-40 to 85 °C
Ambient Relative Humidity 5% to 95% relative humidity (non-condensing)
Vibration (Operative) IEC 60068-2-6 Sinusoidal (5 to 8.4 Hz) 3.5mm /
(8.4 to 150 Hz) 1.0 g; 1 octave/min, 10 cycles per
axis, 3 axes.
Shock (Operative) Half-sine, 15g peak / 11 ms duration, 6 directions
Protection against corrosive
atmospheres (for offshore
installations)
ANSI/ISA S71.04 Class G3
Altitude 2000 meters
