Revision PLC Specific UOC Specific
Check the model number of
the hardware components
See the section Spare parts and model numbers
Plan the architecture of the
system
See the section System
architectures planning
See the section System
architectures
Understand and plan the
hardware components of the
system
See the section Hardware components
Plan the wiring of the system See the section Wiring and cabling planning
Install the racks to house the
system
See the section Rack installation
Install and wire the I/O
modules
See the section I/O Module installation and wiring
Troubleshoot the system See the section Diagnostics and Troubleshooting
Remove or replace system
components
See the section Maintenance
Software configuration See ControlEdge Builder
User’s Guide for PLC
systems.
See Control Building
User’s Guide for UOC
systems.
14
Chapter 2 - Overview
